Ethereum Classic Blocks Explained: The Three Categories

4/28/2017 Christian Seberino

0 pydf21vjXWl8xH12

The Ethereum Classic (ETC) blockchain organizes information into blocks. These help improve performance and minimize storage requirements. Blocks can be divided into headers, transaction lists, and, uncle header lists. It is informative to also consider the following three alternative block element divisions: context, computation and consensus categories.

Context

0 llg1l6DGAToRTcUO

The context, or environment, of all ETC computations must be completely specified. Therefore, blocks contain block numbers, parent header hashes, dates and times. Parents of blocks are the preceding blocks:

Block Numbers

Every block has a unique identifier equal to the number of past blocks. The first (genesis) block has an identifier of zero.

Parent Header Hashes

All block elements, except for the transaction and uncle header lists, form the headers. Every block contains the Keccak 256 hash of the header of its parent. This is partially for security reasons.

Dates & Times

All blocks contain the date and time they were added to the blockchain. This is denoted by the number of seconds since 1970–01–01 00:00:00 UTC.

Computation

0 77XuYYgPihW w1Q4

All ETC computations must be completely specified as well. Therefore, blocks contain transaction lists, transaction list hashes, transaction list gas requirements, transaction list state hashes, transaction receipt list hashes, and, transaction receipt list Bloom filters. It may seem problematic that blocks only contain hashes of states and receipts. This is acceptable because the blockchain contains sufficient information to repeat the entire history of the ETC world computer. Therefore, the blockchain implicitly contains all states and receipts:

Transaction Lists

Entities external to ETC submit jobs as transactions. Blocks contain lists of these transactions.

Transaction List Hashes

Blocks contain the Keccak 256 hashes of special trees formed from their transaction lists. This is partially for security reasons.

Transaction List Gas Requirements

ETC resources are measured in units of gas. Blocks include the number of gas units required to execute their transaction lists.

Transaction List State Hashes

The state refers to all the values in all the accounts. Blocks must specify the states after the transaction lists, and the related chores, have been executed. Therefore, blocks include the Keccak 256 hashes of special trees formed from these states.

Transaction Receipt List Hashes

Execution information for all transactions is included in receipts. These are used by search engines and other applications. Blocks contain the Keccak 256 hashes of special trees formed from their list of transaction receipts.

Transaction Receipt List Bloom Filters

Bloom filters are binary strings used to quickly determine set membership with nominal storage requirements. Blocks contain Bloom filters for their sets of transaction receipt logs.

Consensus

0 NTUJe8yKvJf4WcoT

Mining is the process of creating and validating new blocks. This is referred to as mining because the participants (miners) are rewarded with newly created funds. The mining procedure is referred to as the consensus algorithm. This involves a race to find the proof of work information necessary to create new blocks. The block candidates that lose this race are referred to as the uncles since they are related to the parents. All information pertaining to the consensus algorithm must be specified. Therefore, blocks contain: miner extra data, miner addresses, miner validation helps, miner gas maxima, proof of work information, proof of work difficulty levels, uncle header lists, and, uncle header list hashes:

Miner Extra Data

Miners can optionally include up to an additional 32 bytes in blocks they create. There are no further restrictions on this element.

Miner Addresses

Miners specify account addresses to receive mining rewards in the blocks they create.

Miner Validation Helps

Miners include values to speed up block validation. Blocks could in principle have been designed without these aids. However, some denial of service attacks are possible if block validation is too slow.

Miner Gas Maxima

Blocks specify the maximum possible gas requirements of transaction lists. Miners can adjust these maxima by small amounts relative to the parents.

Proof Of Work Information

Miners can only add new blocks to the blockchain if they compute the proof of work information for those blocks. This proof of work information is included in the blocks.

Proof Of Work Difficulty Levels

The consensus algorithm automatically increases the difficulty level for finding proof of work information when new blocks are being added too quickly. Likewise, the difficulty level decreases when new blocks are being added too slowly. Blocks include their proof of work difficulty levels.

Uncle Header Lists

Blocks contain lists of uncle headers. This improves the security of the blockchain.

Uncle Header List Hashes

Blocks include the Keccak 256 hashes of their uncle header lists. This is partially for security reasons.

Conclusion

1 krAMt9E5V 2 qQnJfPDgJA

Considering these context, computation and consensus categories has hopefully been enlightening. Sometimes different perspectives can make all the difference.
